Технические характеристики
ПроизводительFANUC
МодельFANUC CRX-3iA
КатегорияКоллаборативные роботы
Robot TypeCollaborative
ControllerR-30iB Plus Controller
Motion range — J1400
Motion range — J2360 degrees
Motion range — J3592 degrees
Motion range — J4380 degrees
Motion range — J5360
Motion range — J6450
Electrical connections — Value (V)200-230 V
Electrical connections — Average power consumption0 kW
Integrated Services — Integrated air supply0
Environment — Acoustic noise level70 dB
General attributes — Payload0-10
General attributes — Robot Payload3 kg
General attributes — Robot Reach692 mm
General attributes — Axes6
General attributes — Repeatability (ISO9283)±0.02 mm
General attributes — Mechanical weight11 kg
General attributes — Maximum linear speed1200 mm/sec
General attributes — J4 Moment8.5/ 0.32 (Nm)/Inertia (kgm²)
General attributes — J5 Moment6.5/ 0.24 (Nm)/Inertia (kgm²)
General attributes — J6 Moment4.0/ 0.08 (Nm)/Inertia (kgm²)
General attributes — Robot footprint129
Protection — Body standard/optionalIP67
Protection — Wrist & J3 arm standard/optionalIP67
Ценапо запросу
